EAW manufactures professional loudspeaker systems that help production and integration businesses deliver even, powerful sound to large audiences in challenging acoustic environments. By specifying EAW products, our customers are able to differentiate their services from other providers and thrive in the professional sound marketplace.
EAW’s 40-year history of pioneering techniques and technology helped create the modern professional loudspeaker industry.
In the late 1970s and 1980s, EAW’s MK, FR, and KF Series loudspeaker systems were pivotal in the industry, moving away from home-built cabinets using HiFi or Cinema drivers to purposed designed and engineered “off-the shelf” integrated professional systems.
In the process, EAW created many industry standards facilitating improved quality and
consistency regardless of geographic location. In addition, EAW’s integrated loudspeaker systems pioneered numerous influential advances from materials and build quality to advanced topologies and digital beamforming.
EAW’s early systems (especially the KF850) helped many of the first generation of audio production professionals learn about and ultimately create the professional audio industry. Here is a partial list of EAW innovations and contributions:
1st EAW Public Show - AES Convention NY Waldorf Astoria Introduction of EAW (B-115, B-215, MR-109, B-212, MR-212, MK3000)
• Cross-Grain-Laminated Birch Enclosures
• Polyurethane Reinforced Bass Horn Construction
EAW Introduces 1st Modern Mid-Bass Horn with integrated Phase Plug (MR109) & MK Series 1st “Tour Grade” Full Range Systems
EAW expands with ATC Transducers
• European advanced transducer technology introduced in the USA
• MS50 Studio Monitor
• Minimum diffraction front baffle
• Passive radiator port substitute
• Soft-dome ferro-fluid tweeter
RCF Cost-Effective, Advanced European transducer technology & SM Series Off-the-Shelf “Tour Grade” Stage Monitors
EAW expands with High Output Direct Radiating Studio Monitor (MS300) & Cost Effective Hornloaded Full Range System (FR35o)
EAW, working with Richard Long Associates (RLA), produced worldleading Disco/Dance Clubs Systems
• Pioneered horn-loaded subwoofers
• Hyperbolic Bass Horn
CS-3 1st “One-box” Hornloaded system EAW & Carlo Sound (Combining BH215 bass horn, MR102 midbass horn & Community BRH90 - JBL2440 HF horn/driver)
2nd Generation One-Box “Truck Pack” Optimized Flying System (KF550 System)
• Aircraft Seat-Track Flying hardware
• Horn-loaded mid bass
Cost Effective Professional Full Range Systems (FR Series)
• Cross-Grain-Laminated Birch Enclosures
• Wide coverage waveguide HF driver
• True three-way system
1st Mid-Size Dome Based Studio Monitor (EAW/RCF SCD6000)
• Single massive magnet assembly MH/HF domes
• Fero-Fluid Cooled drivers
1st Compact High Output Dual Driver Stage Monitor (SM202)
Introduction of KF-850, which becomes the world standard “One-box” touring system (KF850/SB850)
• Trapezoid flying array configuration
• Wide bandwidth horizontal coverage control
• Efficient truck-pack 4-across by 2-high
EAW expands the KF range with the KF600, 1st Mid-Format Touring / Install System
• True three-way design
• Integrated slot-loaded low-frequency driver
• Integrated aircraft track hang-points
Anaheim Stadium (Custom AS300 & with Standard EAW Products)
• Custom designed multielement system built to consultant requirements
• 1st ballpark high bandwidth/quality distributed system
• Defined modern arena/stadium sound system design
1st Three-Way Small Format Full Range System for theater market (KF300)
• Carbon fiber cone MF driver
• Switch selectable Bi/Triamplification
• Nicknamed: “ten-pounds of stuff in a five-pound bag”
MX800i Closely Coupled Electronic Processor (CCEP) Introduced
• That Corp. VCA limiters, provide optimized driver protection while maintaining tonal balance
• Internal factory Pre-Sets for the VA family systems
• Factory calibration LED notification
JF Series introduced creating a new class of compact systems for both portable and installed applications
• 1st true pro performance in very compact systems
• Higher output than “typical HiFi based” existing pro compact systems
Disney Lamppost System Early Passive Steering Loudspeaker
•1st steered commercial product, beginning the developments that ultimately leads to EAW’s adaptive systems
•Asymmetrical vertical coverage
•Very complex passive network with a downward lobe
EAW 1st company to offer real detailed Consultant & Contractor design data APP Program
• Electronic distribution
• Dial-up BBS
• One-line web
EAW, working with Peak Audio, installs the first US adaptive sound system in the United States Senate Chamber
• Early Media Matrix DOS computer-based DSP
• Custom speaker high density small driver vertical and horizontal arrays that look like picture frames.
EAW recognized worldwide as leader in Stadium/Arena Sound Systems
• Over 20,000 systems worldwide
• Installed in theaters on five contents
EAW Expands into High End of Retail Pro Loudspeaker Market (LA Series) EAW Quality and Durability for performing musicians
EAW is one of the first Pro Audio sites on the World Wide Web with eaw.com.
• Pioneer for providing design and product in formation on the world wide web
• Sound reinforcement industry online resource center
1st Change in high output distributed ceiling speakers in half a century (CP621)
• Matched directivity and coverage through the crossover region
• Very high output
• Phased array of small LF drivers
Custom engineered systems for multiple Atlanta Olympic venues. KF860 Series Virtual Line Array system debuts at opening & closing ceremonies:
• Adjustable vertical coverage rigging system
• Extremely high output
• Unprecedented broadband rear rejection
Ultra-small frontal area subwoofer as an analog subwoofer power ally solution (SB1000)
• Smallest frontal area of any high output subwoofer system
• Exceptional power handling and output
EAW Fire “The Heat of Fire The Art of Running”
EAW Three-Way Cinema Screen Loud speaker Systems
• 1st fundamental new cinema loud speaker designs in decades.
• Ignited cinema audio advances that resulted in today’s immersive audio environments.
EAW merges with Mackie Designs, bringing together advanced loudspeaker, DSP and amplifier technology in one company (later renamed LOUD Technology)
KF760 EAW’s second generation line array touring loudspeaker
• The first all horn-loaded line array system
• Introduces divergent shading technology
• Advances the design of adjustable rigging systems
EAW introduces the JFX series offering improved performance and better value version of the larger JF systems
EAW Introduces SLAM Line Array providing the cost efficiency of bi-amped three-way system along with phase aligned low frequency subsystem
DSA–the first digitally steerable wide bandwidth array
• 1st fully integrated (loudspeaker/DSP/amplifier) compact wide bandwidth system with computer control
• Created the modern adaptive loudspeaker system
25th Anniversary marking EAW’s 25 years of innovation.
EAW introduces EAW Commercial distributed audio product range
UMX.96 Digital mixing Console with integrated Smaart and Haptic Rotary Controller and high channel count audio over Cat5.
AEAW introduces the AX Series the world’s first wide bandwidth high output symmetrical array system featuring CSA technology
NT Series introduced incorporating EAW/Guinness Focusing that uses DSP to correct loudspeaker anomalies for unmatched impulse response accuracy.
EAW Partners with Rat Sound to bring the MicroWedge family of coax stage monitors to market.
EAW introduces the compact KF740 with CSA™ and Focusing™ technology for outstanding mid and high frequency transient response
Resolution EAW Array Prediction and Control Software, Driven by proprietary EAW FChart acoustics modeling algorithms
EAW Avalon Club series brings advances in form, function, fit and finish united in a pure expression of excellence
Anya world’s first Adaptive Touring Line Array System utilizing high density drivers and beam forming (the culmination of EAW’s20 years of loudspeaker steering development)
Sound Image goes out with Anya for the Tom Petty US Tour
Otto is the world’s first Adaptive™ subwoofer, extending Adaptive Performance™ to the lowest octaves of the audible spectrum
EAW Introduces Anna, providing all of the benefits of Adaptive Performance in a mid-sized enclosure capable of the output of “typical” large format systems
Resolution 2.0 Software–one application for system design, performance modeling, and operation and control of all EAW products
RADIUS introduction the first system with OptiLogic, automatic array self-detection and optimization.
EAW adds QX Series bilaterally symmetrical precise directivity loudspeakers
T.J. Smith new EAW President brings back industry focused management to EAW
RCF purchases EAW from Loud Audio
EAW adds RSX212L Self Powered Line Array System and RSX218 Self Powered Subwoofer System to the RSX Series
New MKD Installation Systems, RSSelf-Powered Series, & KF810 Installation Line Array
EAW introduces NTX & SBX Series
Whitinsville assembly of MKD1200 Series
AC6 ADAPTive Column Speaker
By utilizing multiple closely spaced drivers and processing them individually Adaptive systems are able to provide coverage that is software customizable to your space. This results in even front to back coverage, less spill into adjacent areas, and systems that requires fewer loudspeakers to achieve the same result as larger and heavier systems.
Dynamic Optimization actively tracks input spectrum and power delivery, continually maximizing output and fidelity at any drive level.
A method of seamlessly integrating MF and HF components within a single horn. With CSA, multiple subsystems sum coherently, without interruption to either HF or MF wavefronts.
Symmetrical arrangement of acoustic sources along a common axis for utmost consistency throughout the coverage pattern.
Use of advanced digital signal processing to perfect the impulse response of a loudspeaker in the time domain. Eliminating horn “honk” and splashiness, this makes the loudspeaker sound more like a studio monitor than a “PA” speaker.
Tuned spacing of LF components to extend pattern control without the need for enormous horns.
Introduced over a decade ago for our MK series loudspeakers, EAW Engineers use carefully-designed HF horns and crossovers to eliminate polar irregularities through the crossover point.
TJ is an involved global business leader with over 20 years’ experience in sales,
operations and product development. His dedication and enthusiasm contribute to a thriving work environment determined to engineer and manufacture products that provide creative loudspeaker solutions. He prides himself on leading a close knit, interactive team that shares his vision for EAW’s future. In his free time, he enjoys camping and other adventures with his wife and three sons.
John has been in the pro audio industry for 30 years and has tuned hundreds of venues from House of Worship installations to Major Arena and Stadium Tours. He was an established front of house engineer before migrating towards system design and integration. When not traveling the country, he enjoys tinkering with electronic projects and 3d printing.
Jonas has a long history as an experienced application engineer. Since being with EAW, he has become well known as a valuable training asset to all those who’ve attended one of his events. When not supporting his clients, he can often be found sailing in his
1987 Catalina 30 off the coast of California.
James has been with EAW for over 20 years, starting off as a Product Specialist then quickly climbing the ranks. With a background as a system engineer, he has built strong relationships in his region by offering both great communication and outstanding support with his extensive knowledge of tour sound and the pro audio industry. When not at his office in Kuala Lumpur or travelling the region for meetings and events, he enjoys spending time at home with his family.
Geoff leads EAW’s team of talented and dedicated engineers to develop great sounding loudspeakers that EAW partners can rely on every day. A hands-on industry veteran with a background in system design and consulting, Geoff has been with EAW since 2010. His passion for innovation in the pro audio industry has resulted in the award of nine patents as an inventor. When not in the office, Geoff enjoys swimming, biking, cooking, and spending time with his family.
Richard boasts over 20 years in the industry, with many different roles most recently including project manager of Alesis Drums. He uses his vast knowledge to provide world class support to users new and old. When he’s not creating an exceptional customer service experience, he is a very active DJ throughout the New England region.
Steve has been a valuable member of the EAW team throughout the years. From being a technical sales manager, to a part of the application group, he has been vital to the company’s success. When not working at his home in England, he likes to spend time with his many rescue animals, ranging from rabbits up to horses.
Bryan Develops training programs for all EAW Products and technologies for both internal and external use. He has strong roots in customer service and has also owned his own recording studio. When not working in the office, he is an avid outdoorsman throughout the New England area.
