3-WAY FULL-RANGE ADAPTIVE ARRAY MODULE

Subsystem

LF 2× 10-in cone, 3 in voice coil
MF 4× 5-in cone, 38mm voice coil
HF 8×1-in exit, 35mm voice coil

Nominal Beamwidth

Horz 100° (for single column; scalable up to 360° utilizing multiple columns)

Vert Adaptive

Frequency

45 Hz to 18 kHz

Max SPL

147 dB

3-WAY FULL-RANGE ADAPTIVE ARRAY MODULE

Subsystem

LF 2× 15-in cone, 4 in voice coil
MF 6× 5-in cone, 38mm voice coil
HF 14×1-in exit, 35mm voice coil

Nominal Beamwidth

Horz 70° (for single column; scalable up to 360° utilizing multiple columns)
Vert Adaptive

Frequency

35 Hz to 18 kHz

Max SPL

152 dB

3-WAY LINE ARRAY MODULE

Subsystem

LF – 2x 6 in. 1.75 in voice coil cone driver
MF – 2x 6 in. 1.75 in voice coil cone driver
HF – 6x 1 in. dome tweeter

Nominal Beamwidth

Horizontal: 110
Vertical: 12

Frequency

75hz – 19khz

Max SPL

132 dB

3-WAY LINE ARRAY MODULE

Subsystem

LF 2 x 10 in cone
MF 2 x 7 in cone (horn loaded)
HF 2 x 1 in exit, 1.75 in voice coil compression driver

Nominal Beamwidth

Horizontal: 110
Vertical: 12

Frequency

60hz – 19khz

Max SPL

142 dB

3-WAY LINE ARRAY MODULE

Subsystem

LF – 4x 10 in cone
MF – 2x 8 in. cone
HF – 2x 1.4 in. exit, 2.5 in. voice coil compression driver

Nominal Beamwidth

Horizontal: 90
Vertical: 12

Frequency

50hz – 19khz

Max SPL

146 dB

INSTALLATION LINE ARRAY

Subsystem

LF 2X 10in, 3.0in VC
MF 4X 5in, 1.7in VC
HF 2X 1.4in exit, 3in VC

Nominal Beamwidth

Horizontal – 110° or 80°
Vertical – 10°

Frequency

50 Hz to 20 kHz

Max SPL

145dB

Powered 10" Line Array

Subsystem

LF 2×10″ cone, 2.5″ VC Vented
HF 1×1.4″ exit, 3″ VC compression drivers Isophasic Wave Guide

Nominal Beamwidth

Horizontal: 90°
Vertical: 12°

Frequency

55HZ–18kHz

Max SPL

140 dB

3-WAY SELF-POWERED LOUDSPEAKER

Subsystem

LF – 1 x 8 in cone, 2 in voice coil
LF/MF – 1 x 8 in cone, 2 in voice coil
HF – 2 x 1 in exit, 1.4 in voice coil compression drivers

Nominal Beamwidth

Horizontal 120°
Vertical 12°

Frequency

70 Hz -18 kHz

Max SPL

131 dB

2-WAY SELF-POWERED LOUDSPEAKER

Subsystem

LF – 2 x 12 in cone, 2.5 in voice coil
HF – 2 x 1 in exit, 1.7 in voice coil compression drivers.

Nominal Beamwidth

Horizontal 90°
Vertical 12°

Frequency

50 Hz -19 kHz

Max SPL

142 dB
