SB210

dual 10-inch subwoofer

EAW’s dual 10″ SB210 subwoofer is the latest addition to the revered SB Series product line, offering low frequency support when space is limited

Core Technologies
DynO
SYMMETRY OF SOURCES
Design + Build

Product Description

Key Selling Points

  • Ultra low turbulence port design for superior output
  • Integrated M10 mounting, and M20 pole mount
  • Black, White & WP model available

Finding the right fit

Being a dual 10″ subwoofer, SB210 is the smallest in size of the entire SB series catalog. Finding the right balance between size and performance was no easy task, but we believe the challenge has been met. This means low frequency no longer needs to be sacrificed for space restrictions. SB210 can be suspended, easily fits under most stages, and can hide in corners or against walls of a venue inconspicuously.

Other Features & Benefits

  • Companion UXA4403 amp available
  • Pairs seemlessly with MKC, MK, and MKD Series products
  • Barrier strip and NL4 connections both available on input plate
  • Routed handles on both sides of product for easy transport
  • M20 Pole Mount
The Details Matter

Specifications

Frequency Response
35Hz-150Hz
Max SPL
Whole Space: 128dB
Half Space: 134dB
Operating Mode

VLF, DSP w/ DynO

Subsystem

2x10in cone, 2.5in VC

Nominal Beamwidth
Horizontal 360°
Vertical 360°
Power Handling

500 Watts @ 4 ohms

Connections

2x Neutrik NL4, 2-pin barrier strip

Dimensions

12 x 30 x 19.7in (305 x 762 x 501mm)

Weight

67 lbs. (30.4kg)

Docs / Drawings / Tools

Downloads

Training / Instruction

Videos

Add-on Options

Accessories

Find the Right Speaker

Series Range

SINGLE 18-INCH FLYABLE SUBWOOFER

Subsystem

LF 1×18″, 5.3″ VC

Nominal Beamwidth

Horizontal: 360°
Vertical: 360°

Frequency

32HZ–124Hz

Max SPL

137 dB (Half Space)

DUAL DRIVE SUBWOOFER

Subsystem

2x 15in Cone, 4.5in Voice Coil

Nominal Beamwidth

Horizontal 360°
Vertical 360°

Frequency

27hz – 135hz

Max SPL

138 dB (Half Space)

DUAL DRIVE SUBWOOFER

Subsystem

2x 18in Cone, 4.5in Tetracoil Dual VC, Vented

Nominal Beamwidth

Horizontal 360°
Vertical 360°

Frequency

25hz – 130hz

Max SPL

143 dB (Half Space)

SUBWOOFER

Subsystem

2x 18 in. cone; DSP w/1-way filter

Nominal Beamwidth

Horizontal 360
Vertical 360

Frequency

28hz – 156hz

Max SPL

139 dB (Half Space)

SUBWOOFER

Subsystem

2x 18 in; DSP w/1-way filter

Nominal Beamwidth

Horizontal 360°
Vertical 360°

Frequency

28hz – 160hz

Max SPL

141 dB (Half Space)

SUBWOOFER

Subsystem

2x 18 in. cone; DSP w/1-way filter

Nominal Beamwidth

Horizontal 360°
Vertical 360°

Frequency

28hz – 160hz

Max SPL

141 dB (Half Space)

SUBWOOFER

Subsystem

1 X 12″ Cone

Nominal Beamwidth

Horizontal 360°
Vertical 360°

Frequency

44hz – 152hz

Max SPL

131 dB (Half Space)

SUBWOOFER

Subsystem

1x 15 in. cone

Nominal Beamwidth

Horizontal 360°
Vertical 360°

Frequency

34hz – 145hz

Max SPL

133 dB (Half Space)

SUBWOOFER

Subsystem

1x 18 in. cone

Nominal Beamwidth

Horizontal 360°
Vertical 360°

Frequency

29hz – 150hz

Max SPL

134 dB (Half Space)

DUAL 21-INCH CONE DRIVER SUBWOOFER

Subsystem

2x 21 in. cone

Nominal Beamwidth

Horizontal 360°
Vertical 360°

Frequency

20hz – 190hz

Max SPL

143 dB (Half Space)

SUBWOOFER

Subsystem

2x 15 in. cone

Nominal Beamwidth

Horizontal 360°
Vertical 360°

Frequency

36hz – 150hz

Max SPL

139 dB (Half Space)

SUBWOOFER

Subsystem

2x 18 in. cone

Nominal Beamwidth

Horizontal 360°
Vertical 360°

Frequency

27hz – 147hz

Max SPL

141 dB (Half Space)
