NEW ARRIVAL

RS Series

Our new family of RS Series 2-way self-powered loud speakers and subwoofers brings you EAW signature performance in a portable and lightweight package. Designed around the latest breed of touring grade HF and LF transducers, the new RS Series is also packed with intelligent EAW Core Technology producing studio monitor quality sound.

EAW quality sound in a portable package.

Our new RS Series is a family of 2-ways and subwoofers that utilise leading-edge touring-grade transducers and EAW Core Technology to produce unmatched fidelity and accuracy.

The loud speakers benefit from EAW Focussing™, advanced digital signal processing that perfects the impulse response of a loudspeaker in the time domain. This eliminates horn “honk” and splashiness, giving the loudspeaker the quality of studio monitor sound instead of a “PA” speaker.

Pattern control of the RS Series loud speaker is further enhanced by the unique, constant directivity HF horn; a design theory first proven in our legendary MK Series, a series born from the audio performance needs of stadiums throughout the world.

The RS subwoofers offer 1500 watts of Class-D Power Factor Corrected amplification. EAW Core Technology, in the form of DynO™, makes sure all that power is accurately directed and sounds great for every member of the audience.

Match the RS Series to the latest version of Resolution, our easy-to-use simulation software, and you get the ability to accurately predict the performance of one or multiple RS Series enclosures within your venue. The perfect set of tools and a stunning result.

Our new RS Series is perfectly suited to:

Theatres, auditoria and performing arts centres
Live production/regional rental houses
Live music and dance clubs
Corporate AV events
Houses of worship
Dry hire

RS 2-way loud speakers

Features

Benefits

Latest breed touring grade HF and LF transducers

The highest quality sound in the most demanding conditions

Advanced lightweight and durable wooden enclosure with M10 threaded suspension points

Versatility and ease of handling. Eliminates enclosure resonance. Ease of handling and flexibility

Rotatable MK inspired horn for EAW signature pattern control

Consistent high frequency performance throughout the coverage area

EAW DSP and Core Technology

Unmatched musical clarity and tonal accuracy

RS subwoofers

Features

Benefits

Premium transducers and signature EAW DynO™ dynamic optimisation processing

Continually maximise output and fidelity at any drive level

1500 watts of Class-D Power Factor Corrected amplification

The power you need, when you need it

Mode button that toggles between voicings with a button press

Change between Normal and Depth or Punch (boost select frequencies to improve performance in specific applications)

Ergonomic handles, rugged grille, RoadCoat enclosure, pole cup and optional casters

Easy and quick to move and position

RS 2-way loud speakers

Features

Latest breed touring grade HF and LF transducers

Advanced lightweight and durable wooden enclosure with M10 threaded suspension points

Rotatable MK inspired horn for EAW signature pattern control

EAW DSP and Core Technology

Benefits

The highest quality sound in the most demanding conditions

Versatility and ease of handling. Eliminates enclosure resonance. Ease of handling and flexibility

Consistent high frequency performance throughout the coverage area

Unmatched musical clarity and tonal accuracy

RS subwoofers

Features

Premium transducers and signature EAW DynO™ dynamic optimisation processing

1500 or 2500 watts of Class-D Power Factor Corrected amplification

Cardioid pattern can be generated quickly with a button press

Ergonomic handles, rugged grille, RoadCoat enclosure, pole cup and optional casters

Benefits

Continually maximise output and fidelity at any drive level

The power you need, when you need it

Quickly check that all the bass sound is making its way directly to the audience – bass in its place

Easy and quick to move and position

EAW Core Technologies are the foundation of our products and design.

Core technologies featured in the RS Series include:

DynO

Dynamic Optimization actively tracks input spectrum and power delivery, continually maximizing output and fidelity at any drive level.

FOCUSING

Use of advanced digital signal processing to perfect impulse response of a loudspeaker in the time domain. Eliminating horn “honk” and splashiness, the loudspeaker sounds more like a studio monitor than a “PA” speaker.

BEAMWIDTH MATCHED CROSSOVERS

Symmetrical arrangement of acoustic sources along a common axis for utmost consistency throughout the coverage pattern.

Software tools

Every EAW product series works seamlessly with our array of software applications designed to make installation easier and sound optimization a more exact science.

EAW Resolution 2, for example, is the latest version of our powerful and easy-to-use sound simulation software that accurately predicts the performance of multiple arrays within a venue. Driven by EAW’s proprietary F-Chart acoustics modeling software, Resolution is more accurate and powerful than previous generations. By measuring and using 3D acoustic data in a unique combination, it gives you the power to map and predict sound in a more detailed, accurate and controllable way.

Output levels are displayed by varying color using a variety of methods, including 1/3-octave and broadband SPL, A and C weighted. The actual frequency response at any point in a venue can also be viewed. User-defined environmental conditions, specifically temperature and humidity, are factored into these calculations.

Sound technology optimised through the application of powerful and sophisticated software tools.

EAW’s proprietary Resolution 2 modelling software allows you to accurately predict performance and optimize multiple arrays.

RS Series

RS Series

RS115

SELF-POWERED SUBWOOFER

Subsystem

15in Cone, 3 in Voice Coil, Vented

Nominal Beamwidth

Horizontal 360°
Vertical 360°

Frequency

40 Hz -125 Hz

Max SPL

132dB (peak, half space)

RS Series

RS118

SELF-POWERED SUBWOOFER

Subsystem

18in Cone, 3 in Voice Coil, Vented

Nominal Beamwidth

Horizontal 360°
Vertical 360°

Frequency

27 Hz -125 Hz

Max SPL

133dB (peak, half space)

RS Series

RS121

2-WAY SELF-POWERED LOUDSPEAKER

Subsystem

12 in Cone, 2.5 in Voice Coil
1.4 in Voice Coil Compression Driver, 1 in Exit

Nominal Beamwidth

90° Horizontal
60° Vertical

Frequency

55 Hz – 20 kHz

Max SPL

135dB

RS Series

RS123

2-WAY SELF-POWERED LOUDSPEAKER

Subsystem

12 in Cone, 2.5 in Voice Coil
3 in Voice Coil Neodymium Compression Driver, 1.4 in Exit

Nominal Beamwidth

90° Horizontal
60° Vertical

Frequency

55 Hz – 20 kHz

Max SPL

138dB

RS Series

RS151

2-WAY SELF-POWERED LOUDSPEAKER

Subsystem

15 in Cone, 2.5 in Voice Coil
1.7 in Voice Coil Compression Driver, 1 in Exit

Nominal Beamwidth

90° Horizontal
60° Vertical

Frequency

50 Hz – 20 kHz

Max SPL

136dB

RS Series

RS153

2-WAY SELF-POWERED LOUDSPEAKER

Subsystem

15 in Cone, 3 in Voice Coil
3 in Voice Coil Neodymium Compression Driver, 1.4 in Exit

Nominal Beamwidth

90° Horizontal
60° Vertical

Frequency

50 Hz – 20 kHz

Max SPL

138dB
